    Osp Fr 4 Multilayer Pcb Assembly Custom Gerber One Stop Service

    OSP custom gerber one-stop service Multilayer PCB Assembly factory


    Multilayer PCB Assembly Introduction


    Supplier Type:OEM/ODM
    Place of Origin:Beijing , China
    Certificate:ISO9001 : 2016
    PCB type:Rigid, flexible, rigid-flexible
    Service:PCB Design /PCB layout /PCBA/DIP/Component purchase
    Test service:AOI/X-RAY/Function test
    Copper Thickness:0.3 OZ-6OZ
    Base Material:FR-4; High TG FR-4; Aluminum; CEM-1; CEM-3;
    Board Thickness:0.2mm-4mm
    Surface Finishing:HASL, LF HASL, Imm Gold, Imm Silver, OSP etc


    We provide you the right PCB production and assembly solution for meeting your specific needs. Multilayer PCB Assembly can save your money, have shorter lead time, and is of high-quality products. Our assemblers, preparing the PCB boards, procure raw materials & components, finishing quality testing & inspection, assembly it ready for delivery finally.

    Our professional team are experienced in handling this delicate process, aiming to build multifunctional assemblies that serve all your purposes with space limitations to meet your needs.


    Multilayer Circuit Board Assembly Capabilities
    FACTORY CAPABILITIES
    No.Items2020
    1HDI CapabilitiesHDI ELIC(5+2+5)
    2Max layer count46L
    3Board ThicknessCore thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
    4Min.Hole SizeLaser 0.05mm
    Mechnical 0.15
    5Min Line Width/Space0.030mm/0.030mm
    6Copper Thickness1/3oz-6oz
    7Size Max Panel size700x610mm
    8Registration Accuracy+/-0.05mm
    9Routing Accuracy+/-0.05mm
    10Min.BGA PAD0.125mm
    11Max Aspect Ratio10:01
    12Bow and Twist0.50%
    13Impedance Control Tolerance+/-5%
    14Daily output4,000m2 (Max capacity of equipment)
    15Surface FinishingHASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
    16Raw MaterialFR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI
    PCBA Capability
    Material TypeItemMinMax
    PCBDimension (length,width,height.mm)50*40*0.38600*400*4.2
    MaterialFR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
    Surface finishHASL,OSP,Immersion gold,Flash Gold Finger
    ComponentsChip&IC100555mm
    BGA Pitch0.3mm-
    QFP Pitch0.3mm-

    SMT capabilities:


    SMT Assembly: SMT provides a flexible high technology.

    These solutions include:

    7 high-speed placement machines, 7 automatic printers with fiducial alignment, 2 X-ray machines, BGA maintenance machines, ICT test machines


    DIP function:


    A-8 semi-assembly production line with four wave soldering machines

    1 U-shaped automatic assembly line for box-type building products with test stations

    High temperature / low temperature aging test furnace B-4 for products required for aging test

    With time control and temperature control

    All products are 100% inspected and tested during the DIP process

    Haina lean Electronics Co.,Ltd is a competitive China customize pcba for medical breathing machine OEM manufacturer, supplier and vendor, you can get quick turn customize pcba for medical breathing machine production prototypes and samples from our factory.

    Hot Tags: customize pcba for medical breathing machine, China, supplier, manufacturer, factory, OEM manufacturer, vendor, samples, production, prototypes, quick turn


    Multilayer PCB Assembly Process


    1.Solder Paste stenciling
    2.Surface Mount Technology (Pick and Place)
    3.Reflow Soldering
    4.Inspection and Quality Control
    5.Through-Hole Component Insertion (DIP Process)
    6.Final Inspection and Functional Test

    Osp Fr 4 Multilayer Pcb Assembly Custom Gerber One Stop Service


    Our advantage


    Service value

    Independent quotation system to quickly serve the market

    PCB manufacturing

    High-tech PCB and PCB assembly production line

    Material purchasing

    A team of experienced electronic component procurement engineers

    SMT post soldering

    Dust-free workshop, high-end SMT patch processing


    Osp Fr 4 Multilayer Pcb Assembly Custom Gerber One Stop Service


    Delivery Time


    Product TypeQtyNormal lead timeQuick-turn lead time
    SMT+DIP1-501WD-2WD8H
    SMT+DIP51-2002WD-3WD1.5WD
    SMT+DIP201-20003WD-4WD2WD
    SMT+DIP≥20014WD-5WD3WD
    PCBA(2-4Layer)1-502.5WD-3.5WD1WD
    PCBA(2-4Layer)51-20005WD-6WD2.5WD
    PCBA(2-4Layer)≥2001≥7WD5WD
    PCBA(6-10Layer)1-503WD-4WD2.5WD
    PCBA(6-10Layer)51-20007WD-8WD6WD
    PCBA(10-HDILayer)1-507WD-9WD5WD
    PCBA(10-HDILayer)51-20009WD-11WD7WD

    Multilayer PCB Assembly Application Field


    Our products are widely used in communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics.
